RADCOLUBE 500M is a military-grade, synthetic polyalphaolefin (PAO) dielectric heat transfer fluid manufactured in strict accordance with specification MIL-PRF-87252G (superseding MIL-C-87252). Engineered specifically for liquid cooling systems in advanced military aircraft, missile guidance assemblies, airborne radar, and high-density avionics, Radcolube 500M provides superior heat transfer capabilities combined with exceptional dielectric insulating properties. Formulated to be hydrolytically stable and chemically inert, this non-aqueous PAO coolant prevents electrical arcing and dielectric breakdown while protecting high-power transmitters, Active Electronically Scanned Array (AESA) radars, and electronic warfare (EW) suites across extreme environmental temperature swings (-54°C to 135°C+).

Technical Specifications & Chemical Properties

• Manufacturer / Brand: Radco Industries, Inc. / RADCOLUBE®
• Part Number / Series: RADCOLUBE® 500M
• Military Specification: MIL-PRF-87252G (Qualified Product List / QPL Listed)
• NATO Code / Identifier: S-1748
• Fluid Chemistry: Synthetic Polyalphaolefin (PAO) Hydrocarbon Base
• Dielectric Strength: High breakdown voltage rating (> 35 kV), ensuring complete electrical insulation in high-voltage avionics loops
• Kinematic Viscosity:
  • At 40°C (104°F): ~2.0 cSt (optimized for low pump drag and rapid heat transfer)
  • At -54°C (-65°F): ≤ 2,000 cSt (ensures low-resistance cold startup in sub-zero high-altitude environments)
• Flash Point (Pensky-Martens Closed Cup): ≥ 160°C (320°F) for maximum operational safety in enclosed electronics bays
• Hydrolytic & Oxidation Stability: Exceptional resistance to moisture absorption, preventing acid buildup, sludge formation, and dielectric degradation
• Operating Temperature Range: -65°F to 275°F+ (-54°C to 135°C+) continuous thermal management service
• Appearance: Clear, water-white fluid free of sediment and suspended matter
• Material Compatibility: Compatible with aerospace aluminum cold plates, copper alloys, stainless steel lines, fluorosilicone, and Viton (FKM) elastomeric seals

Approved Specifications & Military Conformance:

Radcolube 500M holds official Quality Products List (QPL) status under defense and NATO military standards:

• MIL-PRF-87252G QPL Certified: Qualified under military performance standards for synthetic hydrocarbon dielectric coolant fluids.
• NATO S-1748 Specification: Standardized across allied forces as an approved airborne dielectric coolant for high-density avionics loops.
• Ultra-Clean Particulate Quality: Packaged under cleanroom conditions to satisfy rigid particle count limits for micro-channel cold plate and servovalve protection.

Key Features & Performance Benefits

• MIL-PRF-87252G Compliance: Fully certified PAO coolant designed to meet the exact thermophysical and electrical requirements of military airframe OEMs.
• High Dielectric Breakdown Voltage: Safely isolates high-voltage avionics and radar transmitters, preventing short-circuiting, electrical arcing, and stray current leakage.
• Hydrolytic & Chemical Purity: Formulated without free water or reactive halogens to prevent chemical attack, pitting, and corrosion on electronic substrates.
• Sub-Zero Fluidity & Rapid Heat Dissipation: Maintains low fluid viscosity at -54°C, ensuring immediate thermal protection for active radar modules upon system power-up.

Typical Applications

• Airborne AESA Radar Systems: Primary dielectric coolant for Active Electronically Scanned Array (AESA) radar antennas, pods, and transmitters on fighter aircraft.
• Avionics & Directed Energy Cooling: Circulates through liquid cold plates in high-density computing racks, EW (Electronic Warfare) suites, and laser systems.
• Missile Guidance & Naval Electronics: Used in shipboard radar installations, missile launcher guidance cooling loops, and military ground-based tracking stations.
